| Main motor power
| 7.5kw | notes |
| Traveling motor power
| 0.5kw |
|
| Equipment voltage | 380v 50Hz | customizable |
| Thickness processing range | 0.8-100mm | customizable |
| Maximum machining widt
| 400mm | Polishing length is not limited |
| Belt size | 1650*400mm*2 | Can be equipped with a wire drawing roller |
| Overall dimensions of the equipment | 1300*750*1750 | Package size 1370*820*1800mm |
| Net weight of equipment | 420kg | The gross weight should be 435KG |
| lift platform | Electric lifting |
|
| Overall equipment control | Panel mounted distribution box control, one click start |
